* 4/8/16/32CH 5MP/4MP/1080P video input;
* VGA、HDMI video output;
* Mini 1U Case, 1SATA(Up to 8TB);
* 265AI/H.265+（compatible H.265/H.264）
* 1*10/100/1000Mbps auto-sensing Ethernet port, RJ45 port；
* Automatic networking support, a key to add equipment;
* Support the Onvif protocol;
* Support GB28181;
* Cloud services, P2P, alarm information push to phone;
* Support remote access, support ARSP;
* "Support DHCP, FTP, DNS, DDNS, NTP, UPNP, EMAIL,
* 3G, WIFI, IP search, Alarm center, etc ;"
* Mobile phone remote monitoring (iOS, Android);
* Multi browser access (IE, Chrome, Firefox, Safari);
* Support for more than twenty languages;
* Perfect protection circuit, unique triple watchdog function;
* Support WEB, CMS, VMS, MYEYE Platform;
* Support AI functions config like Face detection and human detect etc.
System
processor
Hi3536D
system
Embedded Linux
Video
Video input
16ch 5M(15fps)/8ch 5M/16ch 1080P
Playback
1ch 5M/2ch1080P
Decode
H.265AI/H.265+（compatible H.265/H.264）
Audio
Compression
G.711a
Intercom
Unsupport
Management
Record mode
Manual>Alarm>Motiondetection>Timing
Inquire mode
Inquire by Time/Calendar/Event/Channel
Storage mode
HDD Storage, Network Storage
Backup
Network, USB, SATA
Interface
POE ports
N/A
HDMI output
1*HDMI (MAX:2K)
VGA output
1*VGA (MAX:1080P)
Audio I/O
0/1（3.5mm mic）
Alarm I/O
0/0
USB Port
2*USB2.0 ports
HDD
1*SATA interface (Up to 8TB)
General
Temperature
0 ℃ - + 55 ℃
Humidity
10% -90% RH
Power supply
12V/2A
Consumption
<10W(Without HDD)
Weight
Around 1.0KG
Dimension
255(L)* 236mm(W)* 44mm(H)
